- 24 -
3. OPERATION
Bulldog
®
3.1 INTRODUCTION
Congratulations on your purchase of a Stone
BULLDOG
®
! You've made an excellent choice!
Bulldog has been specifically designed as the ideal
machine for delivering relentless compacting power
over a wide variety of soils.
Bulldog's quad-roll design delivers serious
performance. Some of the features you'll benefit
from include: zero edge clearance, truly comfortable
controls that are at the right height, the right angle,
and for safety--automatically return to neutral when
released. There is an anti-crush safety bar that stops
the machine when pressure is applied, side and
vandal proof shields, electric start, and central lifting
eye as well as convenient tie-down points. These are
just a few of the features that will make your life
easier.
Bulldog's heavy duty shock mount system provides
exceptional vibration isolation for engine, hydraulic
pump and operator controls. The battery is double
isolated and foam padded from vibration for
extended life.
Stone offers two different machine widths, 24 inch
(607 mm) and 34 inch (864 mm). Each drum is
equipped with scraper bars to insure proper cleaning.
Upon receipt of your BULLDOG, CAREFULLY
CHECK FOR ANY FREIGHT DAMAGE. Any
damage should be immediately reported to the carrier
and a claim registered.
Bulldog is manufactured to the strictest
specifications and inspection procedures. If any
material or manufacturing defects are found, return
the tag on the machine with assembler's signature and
your findings to the manufacturer. We want to know
when a product is less than perfect. We also
welcome any and all input on how the product may
serve you better.
The following instructions were compiled to provide
you information on how to obtain long and trouble
free use of the unit. Periodic maintenance of this unit
is essential. Read the manual in its entirety and
follow the instructions carefully. Failure to do so
may injure yourself or a bystander.
3.2 MACHINE CONFIGURATION
DESCRIPTION
The Stone Bulldog is supplied in two configurations:
1. Manual operation only.
2. Manual/remote operation.
Throughout this book the instructions will address
operation for both manual and remote versions.
Refer to the Technical Data Section to familiarize
yourself with machine controls and components.
3.2.1 Manual Operation Only
A machine configured for manual operation only is
started with the keyswitch. To stop use either the
keyswitch or the red e-stop button. The operation is
controlled through the switches found on the console.
Switch functions are described in Section 3 under
Operation.
Manual starting and control - The machine is started
with the keyswitch. Control is accomplished through
manipulation of hand switches found on the console.
Note: Radio remote on/off switch should be in the
off position.
3.2.2 Manual/Remote Operation
A machine configured for manual or remote
operation will have the addition of the radio set on
the machine.
Remote starting and control - All machine operations
are controlled by the transmitter. To start, press the
on button. To stop, press the stop button.
Control is accomplished through manipulation of the
switches found on the transmitter.
Notes:
1. If the keyswitch is used to start the machine,
all control of the machine is accomplished at
