Thank you very much
for purchasing a STORCH product. You have chose
a quality product. If you would like to suggest an
improvement, or do experience a problem with your
product, please do not hesitate to contact us. Contact
your sales representative, or in urgent cases, contact
us directly.
Yours sincerely,
STORCH Service Department
Tel. +49 (0) 2 02 . 49 20 - 112
Fax +49 (0) 2 02 . 49 20 - 244
Toll-free Service Hotline: 08 00. 7 86 72 47
Toll-free Order Hotline: 08 00. 7 86 72 44
Toll-free Order Fax: 08 00. 7 86 72 43
(only available in Germany)
Table of Contents: Page
Scope of delivery 42
Technical specications 42
Functional description 42-43
Kite marks/Waste water regulations 43
Commissioning 43
Water pressure / Temperature 43
Cleaning attachment 44
Suction hose 44
Suction unit with immersion pump 44
Important notes 45
Safety instructions 45-46
Maintenance / Cleaning 46
Troubleshooting 46-47
Accessories and spares 47
Warranty conditions 48
Declaration of conformity 49
Scope of delivery of your STORCH High Pressure
Water Recovery System 85:
1 x Standard cleaning attachment incl. sealing brus-
hes
1 x High pressure hose 10 m
1 x Suction hose 10 m
1 x Discharge hose 10 m
1 x Suction unit cpl. with lter, immersion pump
and trolley
Connecting lead with ground fault circuit interrupter
protected plug
Technical specications suction unit:
- Voltage A/C 230 V, 50Hz
- Current rating 1 Motor 5.5 A
- Current rating 2 Motors 11 A
- Fuse 16 A
- Suction motor output 2 x 1220 Watt
- Airow max. 5800 L/min
- Length of suction hose max. 30 meters
- Length connecting lead max. 30m,
2.5mm², completely unrolled
- Dimensions of device
L 780mm x W 525mm x H 1310mm
- Weight 45 kg
- Noise level 77 db (A)
Technical specications immersion pump:
A/C 230 V, 50Hz
Current rating 1.4 A
Power input 320 W
Motor speed 2,800 rpm.
Delivery height 1 / 3 / 5 / 7 m.
Volumes 11 / 9 / 6 / 1 cubic meters/hr.
Standard cleaning attachment:
Overall width 150 mm, Overall length 340 mm,
Working width approx. 110 mm
Working pressure 60-200 bar.
Water infeed max. 20 l/min.
Water temperature max. 85 °C.
SAFETY CHECKS:
ENSURE COMPLIANCE WITH APPLICABLE NA-
TIONAL LEGISLATION.
General functional description:
The STORCH High Pressure Water Recovery Sys-
tem captures the water blasted onto a facade (or
any other surface, walls, ceilings, oors) by a high
pressure cleaner: the solid particles contained in the
waste water are ltered out as of a particle diameter
of 0.21 mm so that the treated water can typically
(depending on the local waste water authority's re-
gulations) be discharged into a waste water channel
in an environmentally friendly way. The high pressu-
re hose provided with the machine is attached to the
high pressure cleaner and the cleaning attachment
which blasts the water via an internal rotation nozz-
le onto the surface to be cleaned. The suction unit
creates a vacuum in the cleaning attachment so that
the water
