Strapack i-10 - Page 13

No. Parts No. Description Q'ty Note
1 615-01-10211 End Plate 1
2 660-01-31120 Right Block Spring 3
3 690-01-30130 Press Tension Spring 3
4
690-01-32130 Spring Hook 1
5 JK25-01-10111 M1 Motor Base 1
6 JK25-01-10133 Heater Cam 1
7 JK25-01-10143 Left Press Cam 1
8 JK25-01-10390 Center Press Cam 1
9 JK25-01-10163 Band Guide Cam 1
10 JK25-01-10174 Right Press Cam 1
11 JK25-01-10251 Limit Switch Bracket 1
12 JK25-01-10281 Bearing Holder 1
13 JK25-01-10291 Cam Shaft 1
14 JK25-01-10310 Cam Collar 9.3 1
15 JK25-01-10320 Cam Collar 19.8 1
16 JK25-01-10330 Cam Collar 9.8 1
17
JK25-01-10340 Cam Collar 6.8 1
18
JK25-01-10421
Limit Switch Cam 1
19 JK25-01-10360 Key 6x6x78.5 1
20 JK25-01-10380 Collar For Key 1
21 JK25-01-30111 Guide Box 1
22 JK25-01-30122 Right Block 1
23
JK25-01-30131
Cutter Upper 1
24 JK25-01-30140 Center Block 1
25
JK25-01-30152
Cutter Lower 1
26 JK25-01-30161 Left Block 1
27 JK25-01-30170 Cam Follower Holder 3
28 JK25-01-50112 Right Frame 1
29 JK25-01-50122 Left Frame 1
30
JK25-07-10111
Label : Indication : M1 1
31
JK25-07-10111
Label : Indication : LS2 1
32 0111-104008 HBS,M4X8 2
33 0111-104010 HBS,M4x10 6
34 0111-104015 HBS,M4x15 2
35 0111-105008 HBS,M5x 8 4
36 0111-105010 HBS,M5x10 9
37 0111-105012 HBS,M5x12 4
38
0131-106015 HB,M6x15 1
39 0161-102510 PMS,M2.5x10 2
40 0181-104001 HN,M4 3
41 0121-104015 HSS,M4X15 3
42
0121-104022 HSS,M4X22 1
43 0321-040810 SW,M4 4
44 0321-050905 SW,M5 12
45 0321-061215 SW,M6 1
46 0411-304020 SpringPin,Ø4x20 3
47 0411-305014 SpringPin,Ø5x14 3
48 0511-132012 Stop Ring S-20 2
49 0611-020635 Bearing 635ZZ 3
50 0611-026904 Bearing 6904ZZ 2
51 0750-110098 Micro Switch , ABS111654 1
52 JK25-06-10570 DC Geared Motor Z2D30-24GN-30S, 2GN60K(for Cam Shaft) 1
CAM AND PRESS GROUP
12
