STRAPEX STB 71/73/75ENGLISH
5.3.3 STB 75: Change from 16 mm to 19 mm (
5
/
8
″ to
3
/
4
″)
Required parts Order number
Strap guide rear 19 mm (
3
/
4
″) (8) 1832.041.021
► Remove battery from tool. Remove three cylinder screws Torx (6). Lift rocker lever towards the
handle, remove cylinder screw Torx (7) and strap guide rear 16 mm (
5
/
8
″) (8).
► Remove side cover (5).
► Remove counter-sunk screw Torx (2) and strap guide front 16 mm (1).
► Remove counter-sunk screw Torx (4) and strap guide front 16 mm (3).
► Remove cylinder screw Torx (10) and strap guide rear 16 mm (9).
► Fit side cover (5) (secure cylinder screw with Loctite 222). Install strap guide rear 19 mm (8).
STB 75: Change from 19 mm to 16 mm (
3
/
4
″ to
5
/
8
″)
Required parts Order number
Strap guide front 16 mm (
5
/
8
″) (1) 1832.031.117
Strap guide front 16 mm (
5
/
8
″) (3) 1832.031.067
Strap guide rear 16 mm (
5
/
8
″) (9) 1832.042.048
Strap guide rear 16 mm (
5
/
8
″) (8) 1832.041.022
Counter-sunk screw Torx, M4x6 (2) (4) 1912.204.064
► Remove battery from tool. Remove three cylinder screws Torx (6). Lift rocker lever towards the
handle, remove cylinder screw Torx (7) and strap guide rear 19 mm (
3
/
4
″) (8).
► Remove side cover (5).
► Fit strap guide front 16 mm (1) (secure counter-sunk screw with Loctite 222).
► Fit strap guide front 16 mm (3) (secure counter-sunk screw with Loctite 222).
► Fit strap guide rear 16 mm (9) (secure cylinder screw with Loctite 222).
► Fit side cover (5) (secure cylinder screw with Loctite 222). Install strap guide rear 16 mm (8).
