Strasbaugh Operator Functions
Version 4.0 - February 1998 3 - 61
REMOVAL OF CARRIERS FROM SPINDLES
NOTICE: The procedure below is for single-table machines
ONLY.
For two-table machines, refer to “Carrier Loading and
Unloading for Machines Equipped with a Second Polish
Table”, located on page 3-85U.
WARNING: Always follow the procedure below to remove carriers
from spindles. To prevent damage to table and spindles,
DO NOT allow spindles to drop onto table.
1. Close all doors to the machine.
Select the Auto Polish Cycle Menu:
Operator Action Explanation/Screen Display
2. <F9> Press the F9 key to choose
“Select Menu”.
3. <F1> Display the Auto Polish Cycle
Menu by pressing the F1 key to
select “Auto Cycle”.
Screen displays the Auto Polish
Cycle Menu.
To Next Page
