Operations Model 6DS-SP Planarizer
3 - 68 Version 4.0 - February 1998
Install a new template ring on each carrier:
9. Lay a new template ring on the carrier lip.
10. Replace the clamp ring.
11. Replace the eight 10-32 clamp screws, rotating them clockwise
to snug.
12. Using a torque screwdriver, tighten each of the eight clamp
screws to 80 oz-in, tightening in a diametrically opposite
sequence:
a. Tighten one screw.
b. Move to the opposite side of the carrier and tighten one
screw.
c. Repeat Steps a. and b. until all eight screws have been
torqued.
