Strasbaugh Mechanical Maintenance Procedures
Version 4.0 - February 1998 9 - 5
ORDER OF ADJUSTMENT
Unless otherwise specifically stated in a procedure, when adjusting a component,
always perform any mechanical and pneumatic adjustment(s) before beginning
the software calibration procedures for the component.
• Refer to Maintenance Chapter 9, Mechanical Maintenance Procedures, for
mechanical adjustment procedures.
• Refer to Maintenance Chapter 11, Pneumatic Adjustments, for pneumatic
adjustment procedures.
• Refer to Maintenance Chapter 10, Software Calibration Procedures, for
software calibration procedures.
EXCEPTIONS
For the components shown below, refer to the “Order of Adjustments” located at
the beginning of the appropriate component section for a detailed listing of the
order in which the mechanical, pneumatic, and software calibration adjustments
must be performed.
Elevator and Robot Adjustments
Cleaning Stations
Conditioning Arm
MENUS USED IN THE MECHANICAL
MAINTENANCE PROCEDURES
For detailed information on the Manual Control, Diagnostics, and
Calibration/Configuration menus, refer to Menus Used in Mechanical
Adjustments and Software Calibration Procedures, found in the Software
Calibration chapter of this manual.
