Strasbaugh Mechanical Maintenance Procedures
Version 4.0 - February 1998 9 - 41
23. Install a retaining shim ring onto the plate.
Notes:
To vary the pocket depth, the shim ring sizes listed in the table below
may be installed singly or in combination.
Retaining
Shim Ring Size Color
.005 blue
.003 green
.002 red
.001 orange
24. Referring to Figure 9-12, install the retaining ring on top of the shim
ring:
a. With the notch of the retaining ring down, place the retaining ring
on the shim.
b. Rotate the retaining ring until the notch is positioned 3/4 in. from
the wafer insert positioning hole located at 5 o’clock.
The notch will be positioned at approximately 6 o’clock.
25. Insert the locking disk into the notch of the retaining ring.
26. Install the clamp ring with its notch down and mating to the locking
disk.
27. Insert the eight 8-32 x 3/8 pan head screws into the clamp ring:
a. Install the appropriate bit in a power screwdriver.
b. Set the power screwdriver for approximately 15
inch-pounds of torque.
Note: For the power screwdriver (Item #218197) included in
the Strasbaugh Carrier Tool Kit , a setting of 3
produces approximately 15 inch-pounds of torque.
c. Find the counterbored hole located nearest the notch of the clamp
ring.
