Strasbaugh Mechanical Maintenance Procedures
Version 4.0 - February 1998 9 - 43
10. Set the power screwdriver for approximately 15 inch-pounds of torque.
11. Install the four 8-32 x 1/2 in. screws in the four 8-32 holes:
a. Insert the four screws into the holes.
b. Using the power screwdriver, tighten the screws to approximately
15 inch-pounds of torque.
12. Remove the carrier from the maintenance fixture.
13. Place the carrier on a solid workbench surface positioned with wafer
mounting side (the side with the small holes) up.
14. Install a carrier seal into the two grooves of the wafer side of the carrier.
15. Using isopropyl alcohol, clean the carrier seal and the entire face of the
carrier.
