Maintenance Model 6DS-SP Planarizer
9 - 44 Version 4.0 - February 1998
J. WAFER MOUNTING PLATE ADJUSTMENT - FOR THREE-,
FOUR-, AND FIVE-INCH CARRIERS ONLY
Notes:
This procedure adjusts the wafer pocket depth of the carrier.
Perform whenever the carrier is reassembled.
BEFORE YOU BEGIN
Tools and Parts Recommended
• 6DS-SP ACC 72 Carrier Tool Kit - Item #218327
Note: The Carrier Tool Kit includes the Carrier Adjusting Tool Assembly,
detailed immediately below.
Carrier Adjusting Tool Assembly (Strasbaugh Indicator Depth
Gauge Assembly) - Item #233595
Consisting of:
- Mitutoyo Indicator Depth Gauge - Item #218198
- Indicator Point, Flat Carbide - Item #218199
- Indicator Depth Gauge Holder - Item #218201
• 6DS-SP ACC 58 (125 mm) Carrier Spare Parts Kit - Item #225134
• 6DS-SP ACC 56 (100 mm) Carrier Spare Parts Kit - Item #225133
• 6DS-SP ACC 57 (75 mm) Carrier Spare Parts Kit - Item #225132
Note: Refer to the Appendix of this document for a bill of materials for
each of the six kits shown above.
• plastic block with hole in center large enough to permit carrier top plate
quill socket to extend down through the block while the block supports the
top plate
