Maintenance Model 6DS-SP Planarizer
9 - 66 Version 4.0 - February 1998
Side to Side
5. Adjust screw C as needed to meet the goal:
• To lower the side of the platform nearest screw C, rotate screw C
clockwise.
• To raise the side of the platform nearest screw C, rotate screw C
counterclockwise.
Note: If you can’t get enough movement by adjusting screw C:
• loosen both screw A and screw B and adjust screw C
until the goal is met.
6. Recheck the Front to Rear adjustment.
Repeat the adjustment as needed until Goal 1 is met.
7. Recheck the Side to Side adjustment.
Repeat the adjustment as needed until Goal 1 is met.
GOAL 2
8. When Goal 1 has been met for both Front to Rear and Side to Side, if all
three screws have NOT been tightened to firm, rotate each adjusting
screw an additional 1/8 turn or as needed clockwise:
Note: Rotate all three screws equally when tightening.
a. Rotate screw A 1/8 turn farther or as needed clockwise.
b. Rotate screw B 1/8 turn farther or as needed clockwise.
c. Rotate screw C 1/8 turn farther or as needed clockwise.
9. Remeasure to confirm that Goal 1 continues to be met.
If needed, repeat the adjustments until both Goal 1 and Goal 2 are met
for Front to Rear and Side to Side.
