Strasbaugh Mechanical Maintenance Procedures
Version 4.0 - February 1998 9 - 165
TABLE TRAVEL CYLINDER REED SWITCH
ADJUSTMENTS
A. BEFORE YOU BEGIN
Tools Required
• flat blade screwdriver
TABLE FORWARD REED SWITCH
The table forward position reed switch is located at the end of the table travel air
cylinder nearest the front of the machine.
B. TEST THE PRESENT POSITION AND ADJUST
1. Close all machine doors.
2. Rotate the Compressed Air Supply valve 1/4 turn counterclockwise to
turn the compressed air supply ON.
3. Confirm that the vacuum supply is ON.
