Maintenance Model 6DS-SP Planarizer
9 - 168 Version 4.0 - February 1998
5. Adjust the switch position:
a. Locate and access the rear travel reed switch through the hole in the
motor.
The switch is mounted at the end of the table travel air cylinder
nearest the rear of the machine.
b. Using a flat blade screwdriver, loosen the clamp screw securing the
switch by rotating it counterclockwise.
c. While watching Input 18 at the Diagnostics screen, slide the switch
on the cylinder until the input comes ON.
d. Retighten the clamp screw.
6. Go on to the Table Locking Cylinder Reed Switch Adjustments, below.
