Strasbaugh Mechanical Maintenance Procedures
Version 4.0 - February 1998 9 - 171
7. If needed, adjust the position of the right locking cylinder reed switch:
a. Using a flashlight and a mirror with a long handle, locate the right
locking cylinder reed switch, mounted at the right end of the
locking cylinder.
b. Inserting a flat blade screwdriver with a 24-in. handle across from
the left end of the cylinder, loosen the clamp screw securing the
switch by rotating it counterclockwise.
c. While watching Input 50 at the Diagnostics screen, slide the switch
on the cylinder until the input comes ON.
d. Retighten the clamp screw.
8. When the goal is met, go on to the Table Unlocking Cylinder Reed
Switches, below.
