Maintenance Model 6DS-SP Planarizer
9 - 172 Version 4.0 - February 1998
TABLE UNLOCKING CYLINDER REED SWITCH
ADJUSTMENTS
A. BEFORE YOU BEGIN
Tools Required
• small flat blade screwdriver
B. TEST THE PRESENT POSITION AND ADJUST
1. Close all machine doors.
2. Disengage the table polish position locks and engage the unlock inputs:
a. At the Diagnostics Menu, select Toggle Output and enter 3 to turn
Output 3 (Second Table Lock) OFF, disengaging the table polish
position locks.
b. Select Toggle Output and enter 4 to turn Output 4 (Second Table
Unlock) ON, engaging the unlock inputs.
