Strasbaugh Mechanical Maintenance Procedures
Version 4.0 - February 1998 9 - 175
B. REINSTALL THE LOAD CHUCKS, TABLE, AND SUBTABLE
1. Remove the stainless steel pan:
a. Using a 7/16-in. open end wrench, remove the four 1/4-20 hex head
capscrews, mounted in pairs at each end of the pan on the black
vertical pan supports, by rotating them counterclockwise.
b. Lift the pan off and set it aside.
2. Reinstall the white polypropylene pan:
a. Replace the pan in the machine.
b. Using a 7/32-in. hex key, replace the three button head capscrews
securing the ring by rotating them clockwise to firm.
3. Reinstall the subtable:
a. While aligning the counterbore holes with the holes in the motor
mount, set the subtable in place.
b. Using a 6-mm hex key, replace the six 8 x 1.25-mm x 20- mm long
socket head capscrews located on the top of the subtable and rotate
them clockwise to firm.
