Strasbaugh Software Calibration Procedures
Version 4.0 - February 1998 10 - 29
2. Calculate the new calibration value for the bridge home position
variable:
NEW = Current Value + CALCULATED OFFSET
CALIBRATION (from screen) (from above)
VALUE
Example:
NEW = - 34.325 + .75
CALIBRATION
VALUE
NEW = - 33.575
CALIBRATION
VALUE
WARNING: Always raise the spindles before changing any
bridge position variable.
3. At Page 2 of the Manual Control Menu, select Left Spindle Up/Down
and choose Up to raise the left spindle.
4. Select Right Spindle Up/Down and choose Up to raise the right spindle.
5. Enter the new calibration value for variable 1, Bridge home position.
Example: - 33.575
WARNING: The value for the bridge home position variable
is always negative. A positive number may do
severe damage to the machine!
6. Close the Polish Area Right Side Operator Door.
7. At Page 1 of the Manual Control Menu, select Bridge Move and choose
Load to return the bridge to load position.
