Strasbaugh Software Calibration Procedures
Version 4.0 - February 1998 10 - 37
BRIDGE TABLE 2 POSITION
CALIBRATION
The procedure below establishes a position at which the bridge is centered over
the (optional) second polish table.
CALIBRATION VARIABLE(S) SET DURING THIS PROCEDURE
16 Bridge table 2 position
Second table option
Nominal value: -35 in.
The distance in negative inches from the primary
table center to the exact center of the second
polishing table.
A. BEFORE YOU BEGIN
Tools Required
• precision scale (accurate to .03125 in.)
Turn Machine Power On and Perform Home Sequence Routine
Follow the procedures detailed in the Operator Functions chapter of the 6DS-SP
Operations manual.
