Maintenance Model 6DS-SP Planarizer
10 - 44 Version 4.0 - February 1998
CONDITIONING ARM
CONDITIONING ARM ADJUSTMENT
SERIES--ORDER OF ADJUSTMENT
When adjusting the cleaning stations, be sure to follow the order shown below
for performing the mechanical and pneumatic adjustments and software
calibration procedures.
Note: Procedures are grouped in each chapter by component.
Order Procedure
Location In
Maintenance
Manual
1 Conditioning Arm Switch Adjustments Chapter 9 - Mechanical
Maintenance
Procedures
2 Conditioning Arm Pressure Adjustment Chapter 11- Pneumatic
Adjustments
3 Conditioning Device Air Cylinder Adjustment Chapter 11- Pneumatic
Adjustments
4 Conditioning Device Programmable Arm
Calibration
Chapter 10 - Software
Calibration Procedures
5 Controllable Conditioning Down Force Option
Calibration
Chapter 10 - Software
Calibration Procedures
