Maintenance Model 6DS-SP Planarizer
10 - 54 Version 4.0 - February 1998
18. Select Cond Arm Up/Dn and choose Down to lower the arm.
19. Select Cond Force and enter a test value of 35.
20. Wait for the displayed conditioning force and the Sensotec indicator
reading to stabilize.
21. Read and record as Actual Force the current measured force value
shown on the Sensotec indicator display.
Example: Actual Force: 35
22. Read and record as Display Force the current Conditioning Force value
displayed in the screen status area:
Cond 35.5 lbs
• Record the value as Display Force.
Example: Display Force: 35.5
23. Evaluate the readings:
GOAL:
The actual force value from the Sensotec indicator display
must be within +/- .3 lbs. of the conditioning down force value
displayed in the screen status area LESS the dead weight.
Actual Force Value = Display Force Value - DEAD WEIGHT
(from indicator) (from screen) (from above)
Example: 35 = 35.5 - 2.16
35 = 33.34
Since 33.34 is not within +/- .3 lbs. of 35, our example does not meet
the goal.
a. If the readings do not meet the goal, correct by following the
procedures found in Section E., immediately below .
b. If the readings meet the goal, skip to When a Satisfactory
Adjustment Is Achieved (below).
