Maintenance Model 6DS-SP Planarizer
10 - 92 Version 4.0 - February 1998
E. WHEN A SATISFACTORY ADJUSTMENT IS ACHIEVED
When a satisfactory adjustment is achieved (the positioning goals are met for
both variables), go on to the Right Send (below).
RIGHT SEND
Repeat as for Left Send, making the following substitutions:
1. At the Calibration/Configuration Menu:
104 “Right send robot
pos'n”
and
111 "Robot arm(s)
position RT
send"
2. Substitute right send for left send where appropriate.
LEFT RECEIVE
Repeat as for Left Send, making the following substitutions:
1. At the Calibration/Configuration Menu:
105 “Left recv robot
pos'n”
and
112 "Robot arm(s)
position LT
recv"
2. Substitute left receive for left send where appropriate.
