Maintenance Model 6DS-SP Planarizer
10 - 126 Version 4.0 - February 1998
Turn Machine Power On and Perform Home Sequence Routine
Follow the procedures detailed in the Operator Functions chapter of the 6DS-SP
Operations manual.
PART I
CALIBRATION VARIABLES SET DURING THIS PROCEDURE
66 Left backpressure offset
Nominal value: 0
The "zero" calibration for the left
backpressure.
68 Right backpressure offset
Nominal value: 0
The "zero" calibration for the right
backpressure.
The steps in this section change the value of variable 66, back pressure offset
(variable 68 for right) as needed to cause the status screen display reading for
back pressure to equal 14.7 psia or 0 psig.
A. CHECK THE PRESENT ADJUSTMENT
1. Read the current Left Spindle Back Pressure value displayed in the
screen status area:
For Back Pressure Displayed In Psia
SPNDL left right
Frc .0
BkPr 15.5 15.5 psia
Spd.0
Load .0
Example: BkPr = 15.5 psia
For Back Pressure Displayed In Psig
SPNDL left right
Frc .0
BkPr 1.2 1.2 psig
Spd.0
Load .0
Example: BkPr = 1.2 psia
