2. Calculate the new calibration value for the left spindle force scale
factor:
NEW Actual High Force Value - Actual Low Force Value Current
CALIBRATION = –––––––––––––––––––––––––––––––––––––––––– x Scale
VALUE Display High Force Value - Display Low Force Value Factor
Example:
NEW = _476 - 80.3 x .982
CALIBRATION 500 - 100
VALUE
NEW = 395.7 x .982
CALIBRATION 400
VALUE
NEW = .9714
CALIBRATION
VALUE
NEW = .971 (round to three decimal places)
CALIBRATION
VALUE
3. At the Calibration/Configuration Menu, enter the new calibration value
for the left spindle force scale factor, variable 33, Left force scale
factor.
Example: .971
E. TEST THE NEW ADJUSTMENT
1. Calculate the COMPENSATION WEIGHT for the left carrier:
COMPENSATION = Left Carrier Weight - Load Cell Carrier Weight
WEIGHT (from above) (from above)
Example:
COMPENSATION = 25 - 8
WEIGHT
COMPENSATION = 17
WEIGHT
