Maintenance Model 6DS-SP Planarizer
10 - 148 Version 4.0 - February 1998
2. Fill in the Polish Force Evaluation Table, below, by following Steps a.
through e., summarized immediately below.
Detailed step procedures follow the table with a test value of 50 used as
an example.
Summary:
a. Input the series of test values shown in column (a) of the table for
the Left Force parameter.
b. Record the status screen display for each test value entered.
c. Record the indicator reading for each test value.
d. Calculate the actual force comparison test value for each test value
entered.
e. Calculate the force error for each test value entered.
Table 10-1 Polish Force Evaluation Table
(a)
Test Value
In LBS.
(b)
Status
Screen
Value
(c)
Indicator
Reading
(d)
Actual Force
Comparison
Test Value
(e)
Force
Error
50 50 27 44 6
100
150
200
250
300
350
400
450
500
a. At Page 2 of the Manual Control Menu, select Left Spindle Force and
enter 50 lbs. as a test value.
b. Read the Left Spindle Force value shown in the screen status area and
record it in the table. Example: 50 lbs.
