Strasbaugh Software Calibration Procedures
Version 4.0 - February 1998 10 - 149
c. Read and record the Measured Force value on the Sensotec Portable
Indicator display. Example: 27
d. Calculate and record the actual force comparison test value for the left
spindle force scale factor:
ACTUAL = Indicator + COMPENSATION
FORCE Reading WEIGHT
COMPARISON (from Sensotec) (from above)
TEST VALUE
Example:
ACTUAL = 27 + 17
FORCE
COMPARISON
TEST VALUE
ACTUAL = 44
FORCE
COMPARISON
TEST VALUE
e. Calculate and record the force error using the following formula:
FORCE ERROR = Status Screen - Actual Force Comparison
Display Force Test Value
(from above) (from above)
Example:
FORCE = 50 - 44
ERROR
FORCE = 6
ERROR
