Maintenance Model 6DS-SP Planarizer
10 - 154 Version 4.0 - February 1998
SPINDLE MOVE DOWN CALIBRATION
CALIBRATION VARIABLES SET DURING THIS PROCEDURE
38 Spindles down soft
value
Nominal value: 1300
Sets the pressure, expressed in control counter "counts" that will
be applied to both spindles when being moved down onto a table
before polishing or when being moved down onto single table
machine cleaning stations. This value is determined
experimentally by entering values into counters 12 and 13 in the
Diagnostics Menu and observing the resulting spindle forces.
The spindles must be over the primary polish table for single
table machines and over the second table for two table machines.
A small force, such as 20 lbs, is sufficient.
