Maintenance Model 6DS-SP Planarizer
10 - 162 Version 4.0 - February 1998
B. ADJUSTMENT PROCEDURE
1. Calculate the new calibration value for the Left Spindle Current Offset
variable:
NEW = Current Value + TABLE 1 LOAD Value
CALIBRATION (from screen) (from status area of screen)
VALUE
Example:
NEW = 1.0 + (- 0.9)
CALIBRATION
VALUE
NEW = 0.1
CALIBRATION
VALUE
2. Enter the new value for variable 63, Table current offset.
Example: 0.1
C. TEST THE NEW ADJUSTMENT
1. Repeat the Check Present Calibration section (above) to check the new
adjustment.
2. If needed, repeat the Adjustment Procedure section (above).
