Strasbaugh Software Calibration Procedures
Version 4.0 - February 1998 10 - 165
B. ADJUSTMENT PROCEDURE
1. Determine the TEMPERATURE IN OFFSET:
TEMPERATURE IN = Actual Temperature - COOLING WATER IN
OFFSET (control unit display) (from screen)
Example:
TEMPERATURE IN = 20 - 22.7
OFFSET
TEMPERATURE IN = - 2.7
OFFSET
2. Enter the new value for variable 7, Temp in offset.
Example: -2.7
TEMPERATURE OUT OFFSET
1. Repeat as for the Temperature In Offset procedures, making the
following substitutions:
At the Calibration/Configuration Menu:
6 = TEMPERATURE OUT SCALE FACTOR
8 = TEMPERATURE OUT OFFSET
2. When the goal is met, go on to Temperature In Scale Factor, below.
