Maintenance Model 6DS-SP Planarizer
10 - 166 Version 4.0 - February 1998
TEMPERATURE IN SCALE FACTOR
A. DETERMINE THE CURRENT TEMPERATURE IN SCALE
FACTOR
1. Read and record the value of the Cooling Water Temperature In display
in the screen status area:
Note: The left of the two columns is cooling water “in.”
COOLING WATER
Flow
I/O 22.8 23.2 degC
2. Calculate the temperature in scale factor:
SCALE FACTOR = Actual Temperature / COOLING WATER (IN)
(from control unit (from screen)
display)
Example:
SCALE FACTOR = 20 ÷ 22.8
SCALE FACTOR = .877
3. At the Calibration/Configuration Menu, enter the new value for
variable 5, Temp in scale factor.
Example: .877
