Maintenance Model 6DS-SP Planarizer
11 - 14 Version 4.0 - February 1998
C. ADJUSTMENT PROCEDURE
1. Turn the machine power to OFF by pressing the red <EMERG OFF>
button located on the control panel.
2. Remove the Left Front Service Door.
3. Find the pneumatic regulator positioned under Solenoid 9 of the valve
panel located inside the Left Front Service Door.
4. Rotate the adjustment screw of the regulator clockwise
1/2 turn.
5. Replace the door(s).
6. Power up and home the machine.
7. Retest by repeating Step 7. of Section B., above.
a. If the goal is not met, repeat rotating the adjustment screw of the
regulator in 1/2-turn clockwise increments and retesting as needed
until the goal is met.
b. When the goal is met, go on to the Down Adjustment, below.
DOWNWARD MOTION
B. CHECK CURRENT ADJUSTMENT
1. Replace the door(s).
2. Power up and home the machine.
