1. Product Characteristics
1.1. Overview
Streamax M1-TKH0401 is a functional Mobile Digital Video Recorder specially designed for vehicle
video surveillance. It has a high-speed processor and embedded operating system, combining with the
most advanced H.265 video compression / decompression technology, GPS positioning technology. It
supports video recording in 1080P, 720P, WD1, WHD1, WCIF, D1, HD1 and CIF formats. It is easy to
use with simple design, multi-functions, superior anti-vibration, flexible installation and high reliability.
1.2. Specifications
Function Overview
Preview, Recording, Playback, Network, Locating
System
OS Linux 3.18.20
Control Mode
CP4, mouse, EasyCheck, network (3G/4G/WIFI)
Video
Input
4 channels AHD(1080P)+1 channel IPC(1080P)
Output
1 channel
Total Resource
PAL:
4*720P@25fps(AHD)+1*1080P@30fps(IPC)
or4*1080P@10fps(AHD)+1*1080P@30fps(IPC)
NTSC:
4*720P@30fps(AHD)+1*1080P@30fps(IPC)
or4*1080P@15fps(AHD)+1*1080P@30fps(IPC)
Video Signal Standard
Electrical level: 1Vpp Impedance: 75Ω
Optional NTSC/PAL
Audio
Input
5channels (1 channel IPC audio input)
Output
1channel
Audio Signal Standard
Electrical level: 2Vpp Input impedance: 4.7kΩ
Display
Display Split 1/4/9
OSD GPS information, alarm, vehicle No., speed, date/time
Operation Interface Semi-transparent GUI
Recording
Video/Audio Compression
Video: H.264/H.265
Audio: ADPCM, G.711U
Image Resolution
Analog:
PAL:
1080P(1920X1080), 720P(1280X720),
WD1(928X576), WHD1(928X288), WCIF(464X288),
D1(704X576), HD1(704x288), CIF(352x288)
NTSC:
1080P(1920X1080), 720P(1280X720),
WD1(928X480), WHD1(928X240), WCIF(464X240),
D1(704x480), HD1(704x240),CIF(352x240);
