09
HANDLE
POWER BUTTON
DIRECTION CONTROL SWITCH
(FORWARD/REVERSE)
POWERHEAD
24v 4AH BATTERY
24v BATTERY CHARGING BASE
OPERATING LOCK LEVER
HEX WRENCH
DRIVE SHAFT
BATTERY
CONNECTOR
(B)
(D)
(A)
(C)
KNOW YOUR ICE AUGER
The safe use of this product requires an understanding of the information on the product and in this owner’s manual
as well as a knowledge of the project you are attempting. Before using this product, familiarize yourself with all
operating features and safety rules.
(A) DIRECTION CONTROL SWITCH (FORWARD/REVERSE)
Your ice auger has a direction control switch (forward/reverse) for changing the direction of auger.
(B) OPERATING LOCK LEVER
Setting this operating lock lever in the OFF position helps reduce the possibility of accidental starting when not
in use. When you want to use this auger, you must pull up on the operating lock lever (deadman’s switch)
lock-out trigger first. Then, press down the (
C)
POWER button. Keeping both engaged simultaneously.
(D) BATTERY CONNECTOR
The battery connector is used to connect Powerhead with the Battery.
LITE-FLITE LAZER
TM
DRILL UNIT
