Strobel VEB100 Series Mechanic's Instructions

24 MA_VEB100-1-2-2W-4-5_A3-1_190627_en.doc
Fig. 3
3.1.5 Adjusting the cloth retainer (Fig. 4)
After replacing the stitch plate, check whether the cloth retainer (7) Fig. 3 lies centrally
on the plunger. This is particularly important for roof-shaped plungers/cloth retainers
to ensure that the material is optimally held during sewing.
Fig. 4
