Strobel VEB100 Series Mechanic's Instructions

41 MA_VEB100-1-2-2W-4-5_A3-1_190627_en.doc
3.9.3 Replacing the knife (Fig. 16 und Fig. 17)
ATTENTION!
Switch off machine electrically!
To replace cylinder head screw (2), unscrew it (hold shaft (14) with open-
end wrench 5 mm).
CAUTION: Do not hold onto the rotary knob (15) since the gearwheels can be
damaged!
The nose of knife (3) should sit in the shaft's groove to guarantee the right position for
the thread trimming.
- Turn the main shaft manually and check the trimming position. (Fig. 17)
3.9.4 Cutting position (Fig. 17)
The machine should be positioned in such a way as the pedal is stepped back that the
distance between looper and blade in cutting position is approx. 1 mm.
For Strobel and EFKA controls, this corresponds to parameter 171, position P2E.
Refer also to the sewing drive operating instructions.
3.10 Interval gear (Fig. 15)
Every second rotation, interval gear 1:2 lowers the material support arm (plunger) by
the value given by the interval stroke control.
3.10.1 Setting the interval gear (Fig. 15)
ATTENTION!
Switch off machine electrically!
- Set the stitch depth until the desired stitching results are achieved.
- Turn the regulating button for intervals (3) Fig. 15 clockwise until the desired
interval stroke is achieved.
