Strobel VEB100 Series Mechanic's Instructions

27 MA_VEB100-1-2-2W-4-5_A3-1_190627_en.doc
3.2 Needle lever
3.2.1 Assembly
ATTENTION!
Switch off the machine electrically!
Remove screw (1), move the Thread take-up lever and remove the needle lever. During
installation, please ensure that the needle runs through the centre of the needle
groove and the needle tip is flush with the left needle guide (Fig. 6).
Fig. 6
