19
WWW.STROMLTD.COM
STROM LIMITED
INSTALLATION GUIDE
40mm
3. Ensure that in the suitable position that the back of the controller
once axed to the backplate is not exposed, and that the surface
is ideally non-metalic, and suitable for wall xings that will rmly
support the control and prevent accidental removal.
4. Once the suitable position has been found using a pencil mark
the xing positions on the wall, and use a suitably sized drill bit for
the wall plugs (care should be taken to ensure you are not drilling
through any utilities such as gas, water, or electric. Once drilled and
plugged secure the wall plate in position with the supplied screws.
5. Wire the backplate in accordance with the wiring diagram supplied.
6. Follow the thermostat commissioning procedure.
