2.0 YOUR RECEIVER
2.1 DEFAULT PIN: 0000
2.2 Front Panel
Fig. 1
1. IR Sensor Receives commands from the remote control
2. LED Display Shows channel number and time in standby
3. Mode Indicator LED RED indicates that the receiver is in STANDBY mode. GREEN
indicates that the receiver is in OPERATING mode.
4. Standby/ON button Switches the receiver ON or into Standby
5. USB To connect your USB storage device.
2.3 Rear Panel
Fig. 2
1. ANT IN To connect to your antenna for reception of broadcast signals.
2. ETHERNET To connect to your Ethernet cable (RJ-45) for RSS feeds and
weather forecasts
3. HDMI To connect your receiver with your TV-set using an HDMI cable.
4. S/PDIF Coaxial To connect your receiver to a digital home cinema set, AV
receiver or digital audio amplier.
5. TV SCART To connect your receiver with your TV-set using a SCART cable.
6. Power cord Your receiver requires a supply voltage of 220 – 240 V AC
(Auto-selectable), 50/60Hz +/-5%. Please ensure the local power
specication meets these requirements before connecting your
receiver to the wall outlet.
7. Power switch To power your receiver ON or OFF
2.4 Remote control
Fig. 3
1. q Switches the receiver On/Standby.
Quick press: passive standby – enables quick start-up. Long press
(more than one second): active standby - longer start-up time.
2. ! Mutes all audio outputs of the receiver
3. 0~9 Enter channel number in TV mode or value input in menu
4. TV/R Toggles between TV or RADIO mode.
5. No function
6. FAV Opens the favourite group selection.
7. 9 One step back in menu or back to previous channel.
8. AUDIO Opens the audio* language selection
9. INFO Opens the current channel information; 2x opens the current
event information and 3x the next event information.*
10. EPG Opens the EPG* (Electronic Programme Guide) in TV mode.
