Structural Concepts DO3623R - Refrigeration Slide-Out Exploded Pictorial

15
R
888 Porter Rd. Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
REFRIGERATION SLIDE-OUT EXPLODED PICTORIAL
The following images show the various parts pertaining to the Refrigeration
Unit (that is slid directly out from lower section) to be serviced.
Copper
Tubing
Refrigeration
Service Valve
Sight Glass
Capacitor
Condensing Coil
(and internal fan)
Condensing
Unit
Dryer Filter
Flexible Hose
Connections
Electrical
Junction Box
Condensate
Pan
Copper
Tubing
Receiver
