13
LED LIGHT FIXTURES, CONT’D: REMOVAL AND REPLACEMENT
1. LED Style Light Fixtures
Removal of Faulty LED Lights:
Contact Structural Concepts’ Technical Service
Department for replacement LED lights.
Turn off LED light switch.
To remove faulty LED light, follow these steps:
A. Disconnect plug from LED light.
B. Using both hands, grasp LED light assembly (with its mag-
netic mounting clips). Pull downward and off its shelf (or
header).
C. Remove magnetic mounting clips from LED light by pressing
against flange part of clip with thumb.
See next page for ‘plug-in’ instructions.
LED Light
(Typ.)
LED Clip
(Typ.)
LED Clip
(Typ.)
LED Light
(Typ.)
Model CDR4287A
To Next Page
