Introduction
2
INTRODUCTION
This manual is designed to assist you with the operation of the model 1550 Electric Stretcher. Read it thor-
oughly before using the equipment.
SPECIFICATIONS
Safe Working Load 500 pounds (227 kilograms)
Overall Bed Length/Width 83.5”/34”
Minimum/Maximum Bed Height 22”/35”
Knee Gatch Angle 0 to 30
Fowler Angle 0 to 70 (Electric), 0 to 90 (Crank)
Trendelenburg/Reverse Trendelenburg +18/−18
Electrical Requirements 120 VAC, 60 Hz, 7.0 Amp
Weight of Product 340 pounds (154 kilograms) − standard configuration
400 pounds (181 kilograms) − all options/accessories
Stryker reserves the right to change specifications without notice.
WARNING / CAUTION / NOTE DEFINITION
The words WARNING, CAUTION and NOTE carry special meanings and should be carefully reviewed.
WARNING
Alerts the reader about a situation, which if not avoided, could result in death or serious injury. It may also
describe potential serious adverse reactions and safety hazards.
CAUTION
Alerts the reader of a potentially hazardous situation, which if not avoided, may result in minor or moderate
injury to the user or patient or damage to the equipment or other property. This includes special care neces-
sary for the safe and effective use of the device and the care necessary to avoid damage to a device that
may occur as a result of use or misuse.
NOTE
This provides special information to make maintenance easier or important instructions clearer.
