4. Insert the small end of the hex wrench (0057-011-000) into the removal tool extension (6392-001-406) to loosen the four
bolts.
NNoottee -- You cannot remove the four floor plate bolts as they are self contained within PPeerrffoorrmmaannccee--LLOOAADD.
5. Carefully remove the fastener assembly from the floor plate assembly.
6. If equipped with inductive charging, disconnect the red wire from the red wire and the black wire from the black wire to
disconnect the fastener assembly from the anchor-to-vehicle cable.
To reinstall, see Installing Performance-LOAD.
CChheecckkiinngg tthhee bbaatttteerryy ppoowweerr lleevveell
Use the cot battery LED indictor to check the SSMMRRTT Pak power level. A charged SSMMRRTT Pak, in working condition, provides
up to 2 calls with a 250 pound patient (actual results may vary). The 24 VDC PPoowweerr--PPRROO system and the SSMMRRTT Pak is
rated for 2.4 amp-hours of electric energy.
WWAARRNNIINNGG -- Do not remove the battery when the cot is active.
CCAAUUTTIIOONN -- Always charge the cot battery before you place the product into service. An uncharged or depleted battery may
cause poor product performance.
To check the battery power level, press the retract (-) button on the cot control switch to activate the cot battery LED
indicator. The cot battery LED indicator is located at the foot end control enclosure (shown as a battery symbol).
• The LED is solid green when the battery has a full charge or has an adequate battery power charge.
NNoottee -- For best results, use the SSMMRRTT Pak until the cot battery LED indicator changes from solid green to flashing
amber.
• The LED flashes amber when you need to charge or replace the battery
NNoottee -- The cot battery LED indicator does not have to flash amber before you remove and replace the SSMMRRTT Pak,
however, this is considered to be a best practice. You can remove and recharge the SSMMRRTT Pak at any time.
• The LED is a solid amber to indicate a battery error.
NNoottee
• Only use Stryker approved batteries.
• If equipped with inductive charging, the powered cot fastener automatically charges the SSMMRRTT Pak battery. Automatic
charging occurs when you lock the cot into the powered cot fastener (no cable or connectors required). The cot battery
LED indicator flashes green for a moment to signify that it is charging.
• Automatic charging will only occur with SSMMRRTT Pak batteries.
UUssiinngg aa nnoonn--uuppggrraaddeedd XX--ffrraammee ccoott ffoorr aa mmaassss ccaassuuaallttyy iinncciiddeenntt
You can use some non-compatible cots, including most X-frame cots, in a a mass casualty incident when equipped with the
mass casualty option for PPeerrffoorrmmaannccee--LLOOAADD and a manual Stryker cot fastener.
The loading and unloading operations are the same as the instructions for manual loading and unloading of a cot.
UUnnllooaaddiinngg aa ccoommppaattiibbllee ccoott ffrroomm PPeerrffoorrmmaannccee--LLOOAADD
WWAARRNNIINNGG
• Always load or unload an occupied cot into a vehicle with a minimum of two trained operators.
• Always be ready to support the entire weight of the cot and patient when you unload a cot from the vehicle patient
compartment.
• Always check for sheets, restraints, or debris that may catch in the cot transport wheels or load wheels.
EN 26 6392-009-001 Rev D.3
