11
Model: REF 4208 Sagittal Saw
Size: 8.9 in. [226 mm] height (with battery)
1.6 in. [41 mm] width
6.5 in. [165 mm] length
Weight: 3.4 lbs. [1.54 kg] (with battery)
Speed: 10,000 CPM (STD mode); 12,000 CPM (FAST mode)
Excursion: 5° arc
Duty Cycle: Intermittent Operation - 1 minute on / 4 minutes off 5 times
with a 3 hour rest
Approvals: CSA International
CAN/CSA-C22.2 No. 601.1-M90
UL 60601-1
IEC 60601-1
Equipment Type: Type BF Applied Part
Power Supply: Internally Powered
Enclosure Protection: IPX0 Ordinary Equipment
Environmental Conditions: Operation Storage and Transportation
Temperature:
Relative Humidity:
Atmospheric Pressure:
*Specifications listed are approximate and may vary slightly from unit to unit or by power supply fluctuations.
Specifications*
