Stuart Turner techflo qt - Location - Single Pump; Single Pump Cold Water Supply

- 7 -
Cont ...
2 LOCATION - SINGLE PUMP
2.25 The cold water supply: Must be a DEDICATED AIR FREE supply via a tank
connector, and must be positioned at a slightly lower level (25 mm minimum) than
the feed pipe to the hot water cylinder.
Do not connect to the mains.
Positive Duty Single Pump System
Fig. 4
Static outlet Pressure Max. 6 m
Max. inlet head 6 m Min. inlet head 0.5 m
