SECTION 3 - INTERIOR
Electrical-Fuse & Circuit Breaker Data
Ue trade number of fuse e. g., SFE-l0. Indicate. circuit breaker by ampere capacity suffixed by
letter. "C.B", e.g., 30 C.B. Where fuse or circuit breaker protects multiple circuit. indicate first
use by a letter and repeat the lame letter for all units protected by the same fuse or circuit breaker,
e.g., Parking light: SFE·10 (a), Direction indicator: same asl (a).
Unit Fuse or Circuit Breaker
Headlamp 20 C .B. ( a)
Headlamp beam indicator Same as ( a)
Parking light Same as ( a)
Taillight Same as ( a)
Stop light 15 C.B. (b)
Direction indicator SFE 9
license plate light Same as ( a)
Instrument light Same as ( a)
Ignition light -
Map light -
Dome light Same as (b)
Clock 1 AG 3
Clock light Same as ( a)
Radio SFE 9
Glove compartment light Same as (b)
Courtesy light -
Trunk compartment light Same as (a)
Other
Windshield Wiper 5 C .B.
Trans. O.D. 3 AG 20
Climatizer and Defroster SFE 14
Reference Source:
1956 Passenger Car Shop Manual, Electrical section, page 2.
1956 Automobile Manufacturers Association Consolidated Specification Questionnaire.
