Studebaker SB3500 - LOCATION OF CONTROLS


E-5
LOCATION OF CONTROLS



1
POWER
/ SOURCE BUTTON
9 SKIP FORWARD
BUTTON /
DST
2 PLAY/PAUSE
/ PAIR / SET /
MEM / M+ BUTTON
10 LCD DISPLAY
3 SKIP BACKWARD
BUTTON 11 AUX IN JACK
4 SPEAKER 12 USB CHARGING PORT
5 SNOOZE / DIMMER / SLEEP
BUTTON
13 FM ANTENNA
6 ALARM 1 BUTTON 14 DC IN JACK
7 ALARM 2 BUTTON 15 BATTERY DOOR
8 VOLUME CONTROL






