Technical data
M
ODEL AJ 275 AJ 350 AJ 400 AJ 500 AJ 600 AJ 700
Battery voltage (V) 12 24 48 12 24 48
Input voltage (V) 10.5 - 16 21 - 32 42 - 64 10.5 - 16 21 - 32 42 - 64
C
ontinuous / 30’ power (VA) 200/275 300/350 300/400 400/500 500/600 500/700
S
tand-by / ON @ no load (W) 0.3*/1.9 0.3*/3.3 0.4*/5 0.3/3.8 0.4/8.5 1/10
Maximum efficiency (%) 93 94 94 93 94 94
Dim. 142 x 84 x L (mm) L= 163 240
e
ight (kg) 2.4 2.6 2.6 4.5
Remote control plug (RCM-01) Option Option
Load detect. (Stand-by) 1-20 W with option S V
S
olar charge controller (-S) 10A 15A
M
ODEL AJ 1000 AJ 1300 AJ 2100 AJ 2400
Battery voltage (V) 12 24 12 24
Input voltage (V) 10.5 - 16 21 - 32 10.5 - 16 21 - 32
C
ontinuous / 30’ power (VA) 800/1000 1000/1300 2000/2100 2000/2400
S
tand-by / ON @ no load (W) 0.3 / 9 0.4 / 10 0.5 / 13 0.4 /18
Maximum efficiency (%) 93 94 92 94
Dim. 142 x 84 x L (mm) L= 428 273 x 399 x 117
W
eight in kg. (approx.) 8.5 19 18
Remote control (JT8) Option Option
Load detect. (Stand-by) 1-20 W v V
S
olar charge controller (-S) 25A 30A
O
utput voltage Sine wave 230V +/-5% (115V +/-5%)
Frequency 50 Hz +/- 0.05 % (60 Hz +/-0.05%)
V
entilation From 45° C
O
verheating protection v
O
verload protection v
S
hort circuit protection v
IP protection index IP 30 (AJ 2100-2400 = IP 20)
C
os ϕ
0.1-1
E norm (ECE-R 10) All models in 12 and 24V are certified
* Stand-by supplied along with the option –S (solar charge controller)
