3.2 Primary Power Supply 5045809
A dual redundant PSU is fitte
d, input 90-264VAC, 47-63Hz, 600 W with twin
AC power inputs on standard IEC fixed plugs. In the event that one power
supply fails, the other one takes over the full load without interruption.
3.3 D23m and D21m I/O Subsystem
The Compact Infinity Core connects via A-Link to the new Studer D23m I/O
system. From there, also MADI links to D21m frames are possible.
The D21m I/O subsystem consists of several different analog and digital I/O
cards, general-purpose I/O cards, and cards for serial control.
The D23m I/O system is compatible and also allows D21m cards to be directly
inserted into D23m frames.
For more information on the D21m system please refer to the ‘D21m I/O
System Operating Instructions’ document available from www.studer.ch
in
the ‘Downloads’ - ‘User Guides’ - ‘Studer D21m I/O System’ area.
For more information on the D23m system please refer to the ‘D23m I/O
System Operating Instructions’ document available from www.studer.ch
in
the ‘Downloads’ - ‘User Guides’ - ‘Studer D23m I/O System’ area.
