Studer RCC-03 Quick Guide

Studer Innotec SA
Quick guide RCC-02/-03
14 V 6.1.0 Quick guide
Level
Nr
Xtender parameter description
Factory value
Expert
1345
AC out presence (AUX 2)
No
Expert
1346
Bulk charge phase (AUX 2)
No
Expert
1347
Absorption phase (AUX 2)
No
Expert
1348
Equalization phase (AUX 2)
No
Expert
1350
Floating (AUX 2)
No
Expert
1351
Reduced floating (AUX 2)
No
Expert
1352
Periodic absorption (AUX 2)
No
Inst.
1602
AC-In energy quota (AUX2)
No
Expert
1353
Contact active according to battery voltage (AUX 2)
Expert
1354
Use dynamic compensation of battery level (AUX 2)
No
Expert
1355
Battery voltage 1 activate (AUX 2)
No
Expert
1356
Battery voltage 1 (AUX 2)
12/24/48 Vdc
Expert
1357
Delay 1 (AUX 2)
5 min
Expert
1358
Battery voltage 2 activate (AUX 2)
No
Expert
1359
Battery voltage 2 (AUX 2)
11.5/23/46.1 Vdc
Expert
1360
Delay 2 (AUX 2)
5 min
Expert
1361
Battery voltage 3 activate (AUX 2)
No
Expert
1362
Battery voltage 3 (AUX 2)
11/22.1/44.2 Vdc
Expert
1363
Delay 3 (AUX 2)
5 min
Expert
1364
Battery voltage to deactivate (AUX 2)
12.6/25.2/50.4 Vdc
Expert
1365
Delay to deactivate (AUX 2)
5 min
Expert
1517
Deactivate if battery in floating phase (AUX 2)
No
Expert
1366
Contact active with inverter power or Smart-Boost (AUX 2)
Expert
1367
Inverter power level 1 activate (AUX 2)
No
Expert
1368
Power level 1 (AUX 2)
120 % Pnom
Expert
1369
Time delay 1 (AUX 2)
0 min
Expert
1370
Inverter power level 2 activate (AUX 2)
No
Expert
1371
Power level 2 (AUX 2)
80 % Pnom
Expert
1372
Time delay 2 (AUX 2)
5 min
Expert
1373
Inverter power level 3 activate (AUX 2)
No
Expert
1374
Power level 3 (AUX 2)
50 % Pnom
Expert
1375
Time delay 3 (AUX 2)
30 min
Expert
1376
Inverter power level to deactivate (AUX 2)
40 % Pnom
Expert
1377
Time delay to deactivate (AUX 2)
5 min
Inst.
1504
Contact active according to battery temperature (AUX 2)
With BSP or BTS
Inst.
1457
Contact activated with the temperature of battery (AUX 2)
No
Inst.
1458
Contact activated over (AUX 2)
3 °C
Inst.
1459
Contact deactivated below (AUX 2)
5 °C
Expert
1502
Contact active according to SOC (AUX 2) Only with BSP
Expert
1442
Contact activated with the SOC 1 of battery (AUX 2)
No
Expert
1443
Contact activated below SOC 1 (AUX 2)
50 % SOC
Expert
1590
Delay 1 (AUX 2)
12 hours
Expert
1591
Contact activated with the SOC 2 of battery (AUX 2)
No
Expert
1592
Contact activated below SOC 2 (AUX 2)
30 % SOC
Expert
1593
Delay 2 (AUX 2)
0.2 hours
Expert
1594
Contact activated with the SOC 3 of battery (AUX 2)
No
Expert
1595
Contact activated below SOC 3 (AUX 2)
20 % SOC
