Studer Solsafe concept User Manual

Appendices – Page 6 / 9
Application Note 003
Appendix 5.1, List of parts
The various components listed below are available in kit form at Studer Innotec.
Name of the kit Solsafe-Kit-Compact
Description
Single-phase Solsafe Kit with Compact series
Designation Studer reference Quantity
Single-phase breaker [25A] DISJ-MG-MONO-25A-C 2
Installation relay [16A] REL-INSTAL-16A 1
Contactor three-phase [Allen-Bradley
32A]
REL-CONTACTEUR-3L-32A-230V 4
Mechanical lock block for contactor
REL-CONTACTEUR-BLOC-
VERROU
2
Junction block [Woertz – 6mm
2
– Grey] B-WOERTZ-6#-GRIS 9
Junction block [Woertz – 6mm
2
– Blue] B-WOERTZ-6#-BLEU 5
Junction block [Woertz – 6mm
2
–
Yellow/Green]
B-WOERTZ-6#-JAUNE-VERT 5
Closure for junction block [Woertz]
B-WOERTZ-PAROI-DE-
FERMETURE
2
Fuse block [Woertz – 4mm
2
– Grey] B-WOERTZ-4#-FUSIBLE 3
Locking block [6/6 – Grey] B-BUTEE-PLASTIQUE 2
ARM-01 module (incl. cable of 5 meter) ARM-01 1
Optional
ENS26 [UFEgmbh] ENS26 1
Fuse block [Woertz – 4mm
2
– Grey] B-WOERTZ-4#-FUSIBLE 1
Name of the kit Solsafe-Kit-
X
tende
r
Description
Single-phase Solsafe Kit with Xtender series
Designation Studer reference Quantity
Single-phase breaker [25A] DISJ-MG-MONO-25A-C 2
Installation relay [16A] REL-INSTAL-16A 1
Contactor three-phase [Allen-Bradley
32A]
REL-CONTACTEUR-3L-32A-230V 4
Mechanical lock block
REL-CONTACTEUR-BLOC-
VERROU
2
Junction block [Woertz – 6mm
2
– Grey] B-WOERTZ-6#-GRIS 9
Junction block [Woertz – 6mm
2
– Blue] B-WOERTZ-6#-BLEU 5
Junction block [Woertz – 6mm
2
–
Yellow/Green]
B-WOERTZ-6#-JAUNE-VERT 5
Closure for junction block [Woertz]
B-WOERTZ-PAROI-DE-
FERMETURE
2
Fuse block [Woertz – 4mm
2
– Grey] B-WOERTZ-4#-FUSIBLE 3
Locking block [6/6 – Grey] B-BUTEE-PLASTIQUE 2
SD card with Solsafe preset SD-CARD-SOLSAFE 1
Optional
ENS26 [UFEgmbh] ENS26 1
Fuse block [Woertz – 4mm
2
– Grey] B-WOERTZ-4#-FUSIBLE 1
Name of the kit Solsafe-Kit-
X
tender_3ph
Description
Three-phase Solsafe Kit with Xtender series
Designation Studer reference Quantity
Three-phase breaker [25A] DISJ-MG-TRI-25A-C 2
Installation relay [16A] REL-INSTAL-16A 1
Contactor three-phase [Allen-Bradley
32A]
REL-CONTACTEUR-3L-32A-230V 4
Mechanical lock block
REL-CONTACTEUR-BLOC-
VERROU
2
Junction block [Woertz – 6mm
2
– Grey] B-WOERTZ-6#-GRIS 19
Junction block [Woertz – 6mm
2
– Blue] B-WOERTZ-6#-BLEU 5
Junction block [Woertz – 6mm
2
–
Yellow/Green]
B-WOERTZ-6#-JAUNE-VERT 5
Closure for junction block [Woertz]
B-WOERTZ-PAROI-DE-
FERMETURE
2
Fuse block [Woertz – 4mm
2
– Grey] B-WOERTZ-4#-FUSIBLE 3
Locking block [6/6 – Grey] B-BUTEE-PLASTIQUE 2
SD card with Solsafe preset SD-CARD-SOLSAFE 1
Optional
ENS31 [UFEgmbh] ENS31 1
Fuse block [Woertz – 4mm
2
– Grey] B-WOERTZ-4#-FUSIBLE 3
