Application Note 003

Appendix 1, S-Box scheme (Power)

Grid

(Consumption

counter)

Backup

grid

Inverter-Charger

output

Grid inverter

output

Grid

(Feedin

counter

)

Note :

If the ENS-Module is required,

it re

laces the connections of X4
